Capabilities

PCB Capabilities

Comprehensive PCB fabrication capabilities for your demanding projects

Parameter	Capability
Layer Counts	1 – 32 layers
Materials	FR4, High Tg FR4, Halogen-Free Material, CEM-3, Rogers HF Material
Min. Line Width / Space	3mil / 3mil
Min. Mechanical Drill	0.15mm
Min. Laser Drill	0.075mm
Finished Board Thickness	0.2mm – 6.5mm
Copper Thickness (Outer)	0.5oz – 5oz
Copper Thickness (Inner)	0.5oz – 4oz
Max. Aspect Ratio	10:1
Surface Finishing	HASL, Lead Free HASL, ENIG, OSP, Immersion Tin, Immersion Silver
Solder Mask Color	Green, Blue, Black, White, Red, Yellow, Matte
Silkscreen Color	White, Yellow, Black
Warp and Twist	≤0.75%
Flammability	UL 94V-0
Special Technologies	Gold Finger, Peelable Mask, Blind/Buried Vias, Impedance Control, Rigid-Flex Board
IPC Class Support	Class 2, Class 3
Certifications	ISO 9001, UL, RoHS

Layer Counts 1 – 32 layers

Materials FR4, High Tg FR4, Halogen-Free Material, CEM-3, Rogers HF Material

Min. Line Width / Space 3mil / 3mil

Min. Mechanical Drill 0.15mm

Min. Laser Drill 0.075mm

Finished Board Thickness 0.2mm – 6.5mm

Copper Thickness (Outer) 0.5oz – 5oz

Copper Thickness (Inner) 0.5oz – 4oz

Max. Aspect Ratio 10:1

Surface Finishing HASL, Lead Free HASL, ENIG, OSP, Immersion Tin, Immersion Silver

Solder Mask Color Green, Blue, Black, White, Red, Yellow, Matte

Silkscreen Color White, Yellow, Black

Warp and Twist ≤0.75%

Flammability UL 94V-0

Special Technologies Gold Finger, Peelable Mask, Blind/Buried Vias, Impedance Control, Rigid-Flex Board

IPC Class Support Class 2, Class 3

Certifications ISO 9001, UL, RoHS

PCB Production Equipment

Advanced equipment empowering every stage of PCB manufacturing, from drilling and lamination to plating and inspection.

VIEW ALL EQUIPMENT

Production

Han's CNC Drilling Machine

Production

Automatic PCB Cutting Machine

Production

Automatic Legend Printing Machine

Production

Hole Inspection Machine

Wet Process

Electroless Copper Plating Line

Wet Process

Etching Production Line

Wet Process

Pattern Plating Line

Wet Process

VCP Copper Plating Line

Forming

Automatic Exposure Machine

Forming

Automatic Lamination Machine

Forming

High-Temperature Tunnel Oven

Forming

Legend Inkjet Printer

Inspection

2-Wire & 4-Wire Low Resistance Tester

Inspection

2D Vision Measurement System

Inspection

3D Digital Microscope

Inspection

AOI Repair Station

Inspection

AVI Inspection System

Inspection

Automatic Electrical Tester

Inspection

Flying Probe Tester

Inspection

Manual Electrical Tester

PCBA Capabilities

Full turnkey PCB assembly services from prototype to mass production

Parameter	Capability
SMT Lines	5 fully automated SMT production lines
Placement Capacity	5,000,000+ points/day
Placement Accuracy	±0.025mm
Min. Component Size	0201 package
Max. PCB Size	510mm × 460mm
Min. BGA Pitch	0.3mm
Min. IC Pitch	0.3mm
Supported Packages	01005, 0201, 0402, QFP, QFN, BGA, CSP, Special-shaped components
Through-Hole Lines	2 plug-in lines
Through-Hole Capacity	100,000 points/day
Manual Soldering Lines	2 hand-soldering lines
Testing Methods	AOI, 3D-SPI, X-Ray, FAI, Functional Testing, ICT
Quality Standards	IPC-A-610 Class 2, Class 3, RoHS
ESD Protection	Comprehensive EPA with grounding systems
Min. Order Quantity	1 piece starts
Lead Time	8 hours (components ready)
